Hammasrataste lihvimismasin

Reishauer RZ 150

Full-option CNC gear grinding machine in outstanding condition, previously used in special-purpose machinery manufacturing.

The machine produces up to 200 different gear types/products for special orders in batch sizes from 1 to 10,000.

Manufacturer: Reishauer
Model: RZ 150
Type: CNC Gear Grinding Machine
Year of manufacture: 2006
Serial number: 7XXXX

Machine specifications:
- 2 identical workpiece spindles
- Workpiece spindles with tailstocks
- Turret design
- Enclosed machining area
- External loading and unloading station
- Especially designed for run-in gearings

Equipment:
- Grinding worm profiling device Reishauer RP 120
- Hoffmann belt suction filter system HSF 150
- OLAER cooling unit CD35.02-NE
- OLAER designation PC31.02NE-S
- ELBARON extraction/filter unit RON/A2000V-2V-RH
Nsdpfxoyxrygs Afljkw
- 5-axis robotic automation (optional)

Operating data:
- Total operating hours: approx. 70,569.5 h
- Run-time / part counter workpiece spindle / workstation 1: counter reading 01794635
- Run-time / part counter workpiece spindle / workstation 2: counter reading 002929

Hoffmann belt suction filter system HSF 150
- Connection: 400 V / 50 Hz
- Phases: 3 / PE
- Operating voltage: 400 V
- Connected load: 31.4 kW
- Nominal current: 56.9 A
- Control voltage: 24 V DC
- PLC voltage: 24 V DC
- Valve voltage: 24 V DC
- Lamp voltage: 24 V DC

OLAER cooling unit CD35.02-NE / PC31.02NE-S
- Year of manufacture: 2005
- Refrigerant: R134a
- Fill quantity: 2.1 kg
- Max. permissible operating overpressure HD: 21.7 bar
- Max. permissible operating overpressure ND: 10.6 bar
- Voltage: 400 V / 3 Ph / 50–60 Hz
alternative: 480 V / 3 Ph / 60 Hz
- Max. current: 5 A
- Power: 2.5 kW

ELBARON RON/A2000V-2V-RH
- Year of manufacture: 07/2005
- Weight: 74 kg
- Connection: 3 x 400 V AC / 50 Hz
alternative: 1 x 230 V / 60 Hz
- Power: 3.56 kW
- Current: 7.0 A
- Protection class: IP54
- High voltage max.: 9.9 kV DC
- Current max.: 24.8 mA

Condition:
- Machine under power
- Operated in single-shift to two-shift operation
- Preventatively maintained
- Very well-kept condition
- Comprehensive documentation available

Scope of delivery:
- Without tools
- Without production fixtures
- Without grinding wheels
- 5-axis robotic automation optional
- Comprehensive documentation available

Availability:
- Inspection by appointment
- Available from 06/2026

Sales information:
- Sale as seen and inspected
- Warranty excluded
