Citizen M12 – Šveitsi automaatne treipink

Citizen M12

Citizen CINCOM M12 – Swiss / Sliding Headstock automatic lathe

Year of manufacture: 2000
Year of manufacture of the feeder: 2009

Technical data:

• Max. bar diameter: 12 mm
• Max. turning length: 200 mm
• Main spindle speed: 12,000 rpm
• Spindle power: 2.2 kW
• Counter spindle speed: up to 10,000 rpm
• Number of axes: 7 (C-axis on both spindles)
• Machine weight: 2,580 kg
• Control: CNC Cincom / Mitsubishi M6
• C-axis and driven tools – milling, drilling, threading possible

Equipment:

• LNS Express 332 bar feeder (2009)
• Guide bushings
• Live tools
• Set of fixed holders
• No chip ejector

The set also includes a large set of guide bushings (GB) and bushings for the LNS feeder in various diameters – visible in the photos.

The photos show the complete set of tools for two identical machines that we sell.

• when purchasing both machines – we provide the entire set of bushings
Bljdpoyqvx Aefx Ab Hed
• when purchasing one machine – the tooling will be divided between the machines

Tool list:

Gang tool post:
T1-T5 fixed tools
T6-T8 driven tools (holders included)

Turret:
T20-T29 fixed or live tools, possibility to install more than one tool per station.

Backspindle tool post:

T41-T43 fixed tools, no possibility of installing driven holders

Technical condition:

The machine is in very good condition, after technical inspection, ready for immediate operation.

Application:
Precision automatic lathe for serial production of small turned parts from Ø 1–12 mm bar stock.

Additional information:

• Nameplate: Citizen Watch Co., Ltd., type M-12, no. M212/0257, weight 2580 kg, S/N P10243.
• Full documentation available and possibility of voltage testing.
• Transport and loading at the buyer's request.
