ACMI BLO2FILL puhumismasin, täitja, sulgur, kombiblokk (2026)

ACMI Blasmaschine, Füller, Verschließer, Combiblock

Overview

This blowmoulder, filler and capper combiblock was manufactured by ACMI (Italy). The machine can be operated fully floor level and is a very good solution offering the advantage of a dual-cavity design (one mold = two bottles up to 70mm diameter) achieving an up to 17% reduced footprint vs equivalent output from traditional single-cavity equipment, improving production line accessibility. The increased output on smaller formats allows better utilisation of downstream equipment in the production line, resulting in improved ROI of total investment (100% additional output on smaller formats with less than 36% additional CAPEX).

The BLO2FILL ESF 12/120/20 is designed for the production of PET bottles and subsequent filling and capping in a single integrated system. The machine is suitable for carbonated water, still water and carbonated soft drinks.

Technical data

- Capacity: up to 48,000 bph (500 ml PET)
- Formats: 500 ml PET bottles
- Application: Blowing, filling and capping of PET bottles
- Configuration:

- Rotary stretch blow moulding machine SBF412 (2-cavity configuration)
- Electronic-volumetric filler with 120 valves
- Fully electronic capper (FEC) with 20 heads

- Neck finish: 26/22 GME 30.40
- Cap type: Plastic screw flat / press-on caps
- Filling technology: Electronic-volumetric
- Products: Carbonated water, still water, carbonated soft drinks
- CO₂ content: up to 8.5 g/l
- Max. filling temperature: up to 18°C (carbonated water), 25°C ambient, 12°C (soft drinks)

Scope of Delivery

- Blowmoulder | Acmi | SBF412 | Rotary stretch blow moulding machine (2-cavity) - 100% r-PET and lightweight preform compatible
- Filler | Acmi | ESF | Electronic-volumetric filler with 120 valves
- Capper | Acmi | FEC | 20-head capper for screw and press-on caps
Nodpfjyzc Hpsx Acnolh
- Cap Feeder | Operator level waterfall orientation and feeding
- Preform orienter |Operator level preform feeding
- Preform insertion control | Control system
- Blowing air recovery system | For pre-blow and line
- Cooling system | Water recirculation on combo interface
- Automation package | PLC teleservice, Ethernet, UPS, remote access
- Lubrication system | Automatic centralized lubrication
- Foaming unit | Automatic system
